產品名稱：KSB 攪拌器Amaprop
研究結果就是新的Amaprop,這嶄新，防斷裂的螺旋槳是為優秀水力效果而設計的，質量（重量）減少使運行和便利的維修是靠工程理念和全套的配件來保證的。
上海英帥機電代理的KSB 水泵AmapropDesign
Horizontal submersible agitator with self-cleaning ECB propeller, close- coupled design, equipped with coaxial spur gear, explosion protection to ATEX II G2 T3 or T4.
Applications
In environmental engineering, particulary for circulating, keeping in suspension and inducing flow in municipal and industrial waste water and sludges; in nitrification and denitrification tanks, activated sludge tanks, mixing tanks, final storage tanks, biological phosphate elimination tanks, flocculation tanks and in biogas applications.
Overview of technical data
| Maximum drive rating | 16 kW |
| Type of bearing | Rolling element bearings |
| Drive frequency | 50 Hz / 60 Hz |
| Maximum speed of rotation | 960 1/min |
| Drive voltage | Low voltage |
| eClass assignment | 00000000 |
| Pump set location | Wet well |
| Explosion protection | ATEX II 2GEXDCIIBT4 |
| Max. permissible fluid temperature | 40 002 |
| Main applications | Waste water / sewage |
| Type of installation | Stationary |
| Type of lubrication | Grease lubrication |
| Type of drive | Electric motor |
| Minimum propeller diameter | 800 mm |
| Installation position | Horizontal |
| Self-cleaning | Yes |
| Type of coupling | Direct; Gear |
| Shaft seal type | Mechanical seal |
| Drive | Electric motor |
| Connection to power supply | 400 V, 3~ |
